Description
Product Specifications
| Specification | Details |
|---|---|
| Stroke | 10 mm |
| Weight | 93 g |
| Operating Voltage | DC 12 V ±10% |
| Repeatability | ±0.01 mm |
| Operating Temperature Range | −10°C to +60°C |
| Quiescent Current | 65 mA |
| Peak Current | 2 A |
| Force Sensor Detection Range | −200 N to +200 N |
| Force Sensor Resolution | 1 N |
| Protection Level | IP40 |
| Maximum Force | 150 N |
| Locked-Rotor Force | 200 N |
| Maximum Self-Locking Force | 70 N |
| No-Load Speed | 8 mm/s |
| Full-Load Speed | 5 mm/s |
| No-Load Current | 400 mA |
| Communication Interface | RS485 |
| Motor Type | Coreless Brushless DC Motor |
